2021 Lexus GX460 Power Seats Wiring Diagrams
7 Power Seats wiring diagrams cataloged for the 2021 Lexus GX460. Includes Climate Control Seats Circuit, Heated Steering Wheel Circuit, Passenger Power Seat Circuit and 2 more. Review the protected preview and vehicle details before ordering.
System
Power Seats
Included
7 wiring diagrams
Delivery
Private digital delivery after payment
What this package covers
This listing is tied to one catalog record, not a generic vehicle page. Check the fitment fields, diagram count, representative filename, and preview against the vehicle you are repairing before purchase.
Catalog fitment: 2021 Lexus GX460
Electrical system: Power Seats
7 diagram files in this system package
Representative file: Fig._100_Passenger_Power_Seat_Circuit.svg
Diagrams in this package (7)
- Fig. 97Climate Control Seats Circuit (1 of 2)
- Fig. 98Climate Control Seats Circuit (2 of 2)
- Fig. 99Heated Steering Wheel Circuit
- Fig. 100Passenger Power Seat Circuit
- Fig. 101Rear Folding Seat Circuit (1 of 2)
- Fig. 102Rear Folding Seat Circuit (2 of 2)
- Fig. 103Rear Heated Seats Circuit
Independent catalog notice
