2016 BMW 528i

2016 BMW 528i Radio Wiring Diagrams

19 Radio wiring diagrams cataloged for the 2016 BMW 528i. Includes Base Radio Circuit w/ Active Sound Design, Base Radio Circuit w/o Active Sound Design, Hifi Radio Circuit w/ Active Sound Design and 7 more. Review the protected preview and vehicle details before ordering.

2016 BMW 528i Radio wiring diagram preview
Product preview

System

Radio

Included

19 wiring diagrams

Delivery

Private digital delivery after payment

What this package covers

This listing is tied to one catalog record, not a generic vehicle page. Check the fitment fields, diagram count, representative filename, and preview against the vehicle you are repairing before purchase.

Catalog fitment: 2016 BMW 528i

Electrical system: Radio

19 diagram files in this system package

Representative file: Fig._108_Base_Radio_Circuit_W_Active_Sound_Design_1_of_3.svg

Diagrams in this package (19)

  1. Fig. 108Base Radio Circuit w/ Active Sound Design (1 of 3)
  2. Fig. 109Base Radio Circuit w/ Active Sound Design (2 of 3)
  3. Fig. 110Base Radio Circuit w/ Active Sound Design (3 of 3)
  4. Fig. 111Base Radio Circuit w/o Active Sound Design (1 of 2)
  5. Fig. 112Base Radio Circuit w/o Active Sound Design (2 of 2)
  6. Fig. 113Hifi Radio Circuit w/ Active Sound Design (1 of 3)
  7. Fig. 114Hifi Radio Circuit w/ Active Sound Design (2 of 3)
  8. Fig. 115Hifi Radio Circuit w/ Active Sound Design (3 of 3)
  9. Fig. 116Hifi Radio Circuit w/o Active Sound Design (1 of 2)
  10. Fig. 117Hifi Radio Circuit w/o Active Sound Design (2 of 2)
  11. Fig. 118MOST Data Bus Circuit
  12. Fig. 119Rear Seat Entertainment Circuit
  13. Fig. 120Top Hifi Radio Circuit Except Premium w/ Active Sound Design (1 of 2)
  14. Fig. 121Top Hifi Radio Circuit Except Premium w/ Active Sound Design (2 of 2)
  15. Fig. 122Top Hifi Radio Circuit Except Premium w/o Active Sound Design
  16. Fig. 123Top Hifi Radio Circuit Premium (1 of 3)
  17. Fig. 124Top Hifi Radio Circuit Premium (2 of 3)
  18. Fig. 125Top Hifi Radio Circuit Premium (3 of 3)
  19. Fig. 126Video System Circuit

Independent catalog notice

WireTorque is an independent technical-document catalog and is not affiliated with or endorsed by the vehicle manufacturer. Read how listings are matched, reviewed, and corrected in our content standards.
