2014 Kia Sportage
2014 Kia Sportage Radio Wiring Diagrams
9 Radio wiring diagrams cataloged for the 2014 Kia Sportage. Includes Platform Audio Circuit w/o Navigation w/ Amplifier, Platform Audio Circuit w/o Navigation w/o Amplifier, Premium Radio Circuit w/ Navigation w/ Amplifier and 2 more. Review the protected preview and vehicle details before ordering.
System
Radio
Included
9 wiring diagrams
Delivery
Private digital delivery after payment
What this package covers
This listing is tied to one catalog record, not a generic vehicle page. Check the fitment fields, diagram count, representative filename, and preview against the vehicle you are repairing before purchase.
Catalog fitment: 2014 Kia Sportage
Electrical system: Radio
9 diagram files in this system package
Representative file: Fig._90_Platform_Audio_Circuit_W_O_Navigation_W_Amplifier_1_of_2.svg
Diagrams in this package (9)
- Fig. 90Platform Audio Circuit w/o Navigation w/ Amplifier (1 of 2)
- Fig. 91Platform Audio Circuit w/o Navigation w/ Amplifier (2 of 2)
- Fig. 92Platform Audio Circuit w/o Navigation w/o Amplifier
- Fig. 93Premium Radio Circuit w/ Navigation w/ Amplifier (1 of 3)
- Fig. 94Premium Radio Circuit w/ Navigation w/ Amplifier (2 of 3)
- Fig. 95Premium Radio Circuit w/ Navigation w/ Amplifier (3 of 3)
- Fig. 96UVO Audio Circuit w/o Navigation w/ Amplifier (1 of 2)
- Fig. 97UVO Audio Circuit w/o Navigation w/ Amplifier (2 of 2)
- Fig. 98UVO Audio Circuit w/o Navigation w/o Amplifier
Independent catalog notice
WireTorque is an independent technical-document catalog and is not affiliated with or endorsed by the vehicle manufacturer. Read how listings are matched, reviewed, and corrected in our content standards.
Same vehicle
Related systems for this vehicle
Full vehicle package
31 systems / 118 diagrams for $12.90Save $55.10
